Overview

For over a decade the Elite Tri Sport has been a consistant top seller. That's because it is so versatile. The Elite Tri Sport is the perfect "one size fits all" trailer. Need to move a car? Done. Need to tow your side by sides to the dunes? Done. Need to haul your sleds up to the mountains? Done. You can even help your mother in law move in if needed... The Tri Sport sits lower to the gound than a standard "deck over" seld trailer. This results in a lower center of gravity for your trailer and translates over to a smoother towing trailer. It also comes standard with a 75" front ramp (biggest in the industry) as well as a car rated cable assist rear ramp. You can custom build a Tri Sport to fit your needs and style or add on our new Keith Curtis 711 or Keith Curtis 711 Pro editions for a trailer with awesome amenities. Anyway you choose, with a Tri Sport, you can't go wrong.

Click here for brochure.

*Some photos may show optional features.

Standard Features

  • Tube Aluminum Chassis
  • Adjustable Rear Stabilizer Jacks
  • 3" Radius Extruded Aluminum Roof Header
  • .030 Aluminum Exterior Skin
  • Polished Stainless Steel Nose
  • 24" Tradbrite Front Rock Guard
  • Rubber Torsion Axles
  • All Wheel Electric Brakes
  • 8 Hole Aluminum Wheels and Radial Trailer Tires
  • 2 LED Dome Lights with Switch
  • Flow Thru Venting
  • Crank Up 14"x14" Roof Vent
  • 15"x15" Fuel Access Door
  • Full LED Light Package
  • Encased Wiring
  • Aluminum Fenders
  • 6" Aluminum Skid Plate
  • 1"x1" Tube Aluminum Walls
  • 1.5"x1.5"Tube Aluminum Roof
  • 6'6" Interior Height
  • 5k Drop Leg Jacks
  • 95" Car Rated Rear Ramp with Cable Assist
  • 75" Front Ramp with Caliber Ramp Cleats
  • Rear Beavertail
  • 3/4" PackTite Floor
  • White .030 Aluminum Walls and Ceiling
  • 4 H.D. Floor Ties and 2 L.D. Floor Ties
  • 36" Radius Style RV Side Door with Step and Grab Handle
  • Protective Coating on Jack and Coupler
  • All Exterior Posts and Seams Taped
  • Keyed Bar Latches
  • Insulated Walls and Ceiling

Sizes & Specs

Model Length:

18'

20'

22'

24'

26'

28'

30'

32'

Overall Length:

20' 10" 22' 10" 24' 10" 26' 10" 28' 10" 30' 10" 32' 10" 34' 10"

Overall Width:

102 in. 102 in. 102 in. 102 in. 102 in. 102 in. 102 in. 102 in.

Overall Height:

105 in. 105 in. 105 in. 105 in. 105 in. 105 in. 105 in. 105 in.

Inside Length:

17' 9" 19' 9" 21' 9" 23' 9" 25' 9" 27' 9" 29' 9" 31' 9"

Inside Width:

99.5 in. 99.5 in. 99.5 in. 99.5 in. 99.5 in. 99.5 in. 99.5 in. 99.5 in.

Inside Height:

78.5 in. 78.5 in. 78.5 in. 78.5 in. 78.5 in. 78.5 in. 78.5 in. 78.5 in.

Side Door Dimensions:

72" x 36" 72" x 36" 72" x 36" 72" x 36" 72" x 36" 72" x 36" 72" x 36" 72" x 36"

Rear Ramp Dimensions:

95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25"

Estimated Trailer Weight:



Undercarriage Options

Option 1:

Tandem 5,200 lb. Torsion Axles | ST 225x15D Radial Tires W/6 Hole Wheels | GVWR: 9,990 lb.

Option 2:

Tandem 6,000 lb. Torsion Axles | ST 235x16E Radial Tires W/8 Hole Wheels | GVWR: 12,000 lbs.

Option 3:

Tandem 7,000 lb. Torsion Axles | ST 235x16E Radial Tires W/8 Hole Wheels | GVWR: 14,000 lbs.

Available Packages

Keith Curtis 711 Edition Package

Included Features:

  • 36" Aluminum Diamondplate on Interior Walls
  • Dropped Spread Axles
  • Cast Aluminum Recessed Door Step
  • Black Tiger Aluminum Wheels
  • Spare Tire Mount
  • Caliber Ramp Cleats and LowPro Grip Glides on Front Ramp and Rear Ramp
  • Frameless Window In Side Doors
  • Charmac Backlit Logo
  • Keith Curtis 711 Edition Graphics
  • Rubber Diamond Plate Floor and Ramps
  • 8' Helmet Cabinet
  • 8' Adjustable Clothes Hooks
  • 3M VHB Bonded Exterior Sheeting
  • Black Roll-Over Couch
  • 40,000 BTU Forced Air Furnace Ducted to Cabinet
  • 6 - LED Interior Dome Lights
  • 3 - 4" Exterior LED Loading Lights
  • 12v Wet Cell Battery
  • 110v 15 Amp Converter Package
  • LED Chrome Porch Light Over Side Door

Available Colors

(Custom colors may be available upon request.)

Available Options
