Overview

Tried and true our Elite Snow Sport is a classic with great upgrades such as all aluminum framework, aluminum wheels, and insulation just to name a few. The snow sport maximizes interior deck space because of its' "deck over" style contruction. No interior fenders means un abstucted space on your trailer floor. A cable assist rear ramp and beavertailed makes loading sleds a breeze. It also comes standard with a 75" front ramp (biggest in the industry). You can custom build an Elite Snow Sport to fit your needs and style or add on our new Keith Curtis 711 Edition for a trailer with awesome amenities.

Click here for brochure.

*Some photos may show optional features.

Standard Features

  • Tube Aluminum Chassis
  • 1"x1" Tube Aluminum Walls
  • 1.5"x1.5" Tube Aluminum Roof
  • 6'6" Interior Height
  • 5k Drop Leg Jacks
  • Adjustable Rear Stabilizer Jacks
  • 3" Radius Extruded Aluminum Roof Header
  • .030 Aluminum Exterior Skin
  • Polished Stainless Steel Nose
  • 24" Tradbrite Front Rock Guard
  • Crank up 14"x14" Roof Vent
  • 36" Radius Style RV Door with Step and Grab Handle
  • 15"x15" Fuel Access Door
  • All Exterior Posts and Seams Taped
  • Keyed Bar Laches
  • 75" Front Ramp with Caliber Ramp Cleats
  • Rear Beavertail
  • Rubber Torsion Axles
  • All Wheel Electric Brakes
  • 8 Hole Aluminum Wheels and Radial Trailer Tires
  • 3/4" PackTite Floor
  • White .030 Aluminum Walls and Ceiling
  • 4 H.D. Floor Ties and 2 L.D. Floor Ties
  • 2 LED Dome Lights with Switch
  • Flow Thru Venting
  • Full LED Light Package
  • Protective Coating on Jack and Coupler
  • Insulated Walls and Ceiling
  • 6"Aluminum Skid Plate

Sizes & Specs

Model Length:

18'

20'

22'

24'

26'

28'

30'

32'

Overall Length:

21' 2" 23' 2" 25' 2" 27' 2" 29' 2" 31' 2" 33' 2" 35' 2"

Overall Width:

102 in. 102 in. 102 in. 102 in. 102 in. 102 in. 102 in. 102 in.

Overall Height:

109 in. 109 in. 109 in. 109 in. 109 in. 109 in. 109 in. 109 in.

Inside Length:

18' 4" 20' 4" 22' 4" 24' 4" 26' 4" 28' 4" 30' 4" 32' 4"

Inside Width:

99.5 in. 99.5 in. 99.5 in. 99.5 in. 99.5 in. 99.5 in. 99.5 in. 99.5 in.

Inside Height:

78.5 in. 78.5 in. 78.5 in. 78.5 in. 78.5 in. 78.5 in. 78.5 in. 78.5 in.

Side Door Dimensions:

72" x 36" 72" x 36" 72" x 36" 72" x 36" 72" x 36" 72" x 36" 72" x 36" 72" x 36"

Rear Ramp Dimensions:

95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25" 95.5" x 82.25"

Estimated Trailer Weight:

2,950 lbs. 3,080 lbs. 3,250 lbs. 3,420 lbs. 3,590 lbs. 3,760 lbs 4,130 lbs. 4,300 lbs.

Undercarriage Options

Option 1:

Tandem 3,500 lb. Torsion Axles | ST 205x14C Radial Tires W/5 Hole Wheels | GVWR: 7,000 lbs.

Option 2:

Triple 3,500 lb. Torsion Axles | ST 205x14C Radial Tires W/5 Hole Wheels | GVWR: 10,500 lbs.

Option 3:

Tandem 5,200 lb. Torsion Axles | ST 205x15D Radial Tires W/6 Hole Wheels | GVWR: 9,990 lbs.

Option 4:

Triple 5,200 lb. Torsion Axles | ST 205x15D Radial Tires W/6 Hole Wheels | GVWR: 15,000 lbs.

Available Packages

Keith Curtis 711 Edition Package

Included Features:

  • 36" Aluminum Diamondplate on Interior Walls
  • Cast Aluminum Recessed Door Step
  • Black Tiger Aluminum Wheels
  • Spare Tire Mount
  • Caliber Ramp Cleats and LowPro Grip Glides on Front Ramp and Rear Ramp
  • Frameless Window In Side Doors
  • Charmac Backlit Logo
  • Keith Curtis 711 Edition Graphics
  • Rubber Diamond Plate Floor and Ramps
  • 8' Helmet Cabinet
  • 8' Adjustable Clothes Hooks
  • 3M VHB Bonded Exterior Sheeting
  • Black Roll-Over Couch
  • 40,000 BTU Forced Air Furnace Ducted to Cabinet
  • 6 - LED Interior Dome Lights
  • 3 - 4" Exterior LED Loading Lights
  • 12v Wet Cell Battery
  • 110v 15 Amp Converter Package
  • LED Chrome Porch Light Over Side Door

Available Colors

(Custom colors may be available upon request.)

Available Options
